Draftsman-Surveyor

Orange, CA - USA

Monthly Salary: $ 75000 - 88000

Posted on: 07-11-2025

Vacancies: 1 Vacancy

Job Summary

Qualifications
An ideal candidate would possess the following qualifications:

*Must be willing to travel. 80%
*Must be able to work in a collaborative fast-paced environment.
*Knowledge in the use of Total Station robotic instrument used to collect topographic data produce drawings and perform site layouts.
*Drafting experience in Surveying (LiDAR GPS Total Stations) (Surveying equipment: Trimble Carlson).
Experience using 3D laser scanner (Leica RTC 360) and scan rendering software (Register 360).
Produce 2D drawings using AutoCAD and/or Civil 3D software.
Drone operating experience.
Bilingual in English and Spanish

* Requirements for position.
NOTE: Items without a * are not required but they are preferred. Candidate can be trained in
those sections if they are hired.

Responsibilities
The primary responsibilities of the employee include:

Assist engineering department in retrieving field data measurements and other information to produce 2D drawings for structures assemblies site plans and utilities in AutoCAD or Civil 3D format.

Perform site and building surveys.
Produce drawings from field recovered data and surveys under the direction of the engineering department.

Generate diagrams demonstrating the order of process equipment.
Superimpose 2D drawings from engineering team over surveys to identify potential conflicts with existing structures and equipment.

Generate shop drawings of designs made by engineering team.
Scan facilities using the 3D laser scanner and then processing the data using Register 360software.

Create scaled aerial photographs of facilities using a drone.

Physical Requirements
Work Environment: Scarp metal yard outdoor.
Equipment & Tools: Yard equipment hand tools and PPE.
Physical demand level: Moderate to heavy.
Work capacity: Laborer work capacity.
Hand Movements: Repetitive motions.

$75000 - $88000 Depending on experience
